LABORATORY CBR TESTER, Multi-Speed (T003)
Category: Soil
Product Code: T003
Category: SOIL
Sub-Category: CALIFORNIA BEARING RATIO
- The California Bearing Ratio (CBR) is a penetration test carried out to evaluate the mechanical strength of road subgrades and base-coarse layers.
- Equipped with an TFT controlling unit.
- Has a capacity of 50 kN and automatically performs the test, with an automatic stop after finishing the test and returning to initial position.
- The TFT screen shows the Loading and Penetration in a real time during the test.
- Can be connected to PC via USB cable; allowing trasnfer of data in realtime to PC via USB to plot load vs. penetration graph
STANDARDS
ASTM 1883 • BS 1377-4 • EN 13286-47
TECHNICAL SPECIFICATIONS
- Capacity : 50 kN
- Touch Screen Load/Flow Indicator with PC Software for Data Collection
- High Precision Load Cell
- Electronic Measure of Penetration
- Peak Hold of Load and Penetration
- Equipped with TFT Indicator
- Load Rate: 1.00, 1.27 and 2.50 mm/min
- 220 – 240 V / 50 – 60 Hz
ORDERING INFORMATION
| Item | Code |
| LAB. CBR APPARATUS – TFT | T001A05XU |
| LAB. CBR APPARATUS – Load Ring | T001L05XU |
| LAB. CBR APPARATUS – Digital | T001M05XU |
| SPARE LOAD/DEFORMATION INDICATOR for T001M | T001P001X |
| CBR PENETRATION PISTON | T001P002X |
| FIELD CBR SET | T002L05XH |
| CONVERSION FRAME for T-001/F | T002P001H |
| LAB. CBR APPARATUS – Digital – Multi-Speed | T003M05XU |
